Compact Portable Military Managed Gigabit Ethernet Switch and Router

The MILTECH 9012 is a unique combination of both a Layer 2 Ethernet switch and a Layer 3 Ethernet router. It is an ideal solution for connecting IP-based voice, video, sensor data acquisition, and other communication devices that require both on-vehicle LAN management and off-vehicle WAN connectivity.

This highly-integrated, compact form factor switch/router saves valuable real estate on mobile military platforms including:
Battle management systems (BMSs), UAVs, Manned and autonomous land vehicles (UGVs), Robots, Mobile equipment fielded in harsh environment.



download datasheet

Product Description

The MILTECH 9012 features both L2/L3 network switching and routing capabilities, including virtual LANS (VLANS), traffic prioritization/QoS, IPv4/IPv6 dynamic routing, and bandwidth aggregation. It supports all the latest networking protocols for redundancy, security, multicast, and management. Remote management allows for centralized traffic optimization and prioritization of mission-critical data.

The MILTECH 9012 is a member of the MILTECH 9012 family that offers flexible alternatives for LAN, LAN/WAN, and customizable networking. All family members are MIL-STD, fully managed, and military grade, with 12 triple-speed (10/100/1000Mbps) ports. The MILTECH 9012 uses industry-standard 24VDC power and is designed for MIL-STD-810F, MIL-STD-461E, MIL-STD-1275B & MIL-STD-704A airborne, ground mobile environmental, EMI/RFI compliance with high reliability.




Product Model MILTECH 9012
Management Managed
Ports 12 x 10/100/1000
DIMS 166.4 mm x 144 mm x 56 mm
Connector Power + LAN : SCE2
Weight 1.1Kg
Operating Temp -45°C to +85°C
Power 18-70VDC, 13W (Typical)
